Phanteks M25-140 PWM D-RGB White 140mm Cooler Fan (PH-F140 M25_DRGB_PWM_WT01)

₱897.00
₱897.00
Availability: In stock
SKU:
Collections:
PhanteksPhanteks M25-140 PWM D-RGB Black 3-Pack 140mm Cooler Fan (PH-F140M25_DRGB_PWM_BK01_3P)
Phanteks M25-140 PWM D-RGB Black 3-Pack 140mm Cooler Fan (PH-F140M25_DRGB_PWM_BK01_3P)
Phanteks M25-140 PWM D-RGB White 3-Pack 140mm Cooler Fan (PH-F140M25_DRGB_PWM_WT01_3P)
PhanteksPhanteks M25-140 PWM D-RGB White 3-Pack 140mm Cooler Fan (PH-F140M25_DRGB_PWM_WT01_3P)
₱897.00
₱897.00
  1. 1
  2. 2
  3. 3
  4. 4
  5. 5

M25-140

Designed to deliver high air flow cooling performance

The Phanteks M25 fan builds upon the award winning T30 fan to keep next gen hardware cool with high airflow cooling performance. The M25 fan blades are specifically optimized to perform the best with fine mesh/dust filters, heatsinks and radiators with reduced RPM levels. This optimization keeps unwanted bearing noises at a minimum while also leaving plenty of cooling headroom when necessary by going full speed.


Colors

Black

Black D-RGB

White D-RGB



Dimensions

120

140


Optimized for Performance

  • Optimized for heatsinks and radiators to maximize CPU and GPU performance.

  • High cooling capacity at 2000 RPM to cool even the most power ful hardware components.

  • Excellent low noise performance thanks to a high air flow/RPM ratio to minimize bearing and motor noises.

Daisy-chain Connection

  • Clutter-free cable management with both fan and D-RGB daisy-chain connection.

  • Connect multiple fans together with a single PWM extension cable.

Colorful D-RGB Lighting

  • Built-in D-RGB LEDs for smooth lighting effects.

  • Daisy chain D-RGB connectors for easy cable management.

  • Compatible with all Phanteks cases.

  • Optionally sync with mainboard and software.

Asus Auro Sync | RGB Fusion 2.0 | MSI Mystic Light Sync | ASRock Polychrome Sync | Razer Chroma | NexLinq

Specifications

General

Model No.

PH-F140M25_DRGB_PWM_WT01 | PH-F140M25_DRGB_PWM_WT01_3P

UPC Code

886523002512 | 886523002451

Frame Size

140 x 140 x 25 mm | 5.51 x 5.51 x 0.98 in

Blade Geometry

Nine blades design

PWM Connector

4-Pin Daisy-chain

PWM Cable Length

140 + 500 mm | 5.51 + 19.68 in Extension cable

D-RGB Connector

3-Pin D-RGB Daisy-Chain

D-RGB Cable Length

300 + 100 mm | 11.8 + 3.9 in

TECHNICAL DETAILS

Bearing Type

Hydraulic bearing

Rated Voltage

12V

Noise Level

36.57 dBA

Max. Airflow

104.62 CFM

Max. Air Pressure

2.80 mm H2O

Speed

500~1800 ± 10% RPM

MTFB

30.000 hours

Max Current

0.28A

Max Power

2.40W

Operating Voltage Range

DC 7 – 13.2V

LED Number

12

LED Rated Current

Max. 0.25 ± 0.04A

Single Pack

Triple Pack

Net Weight

195 g | 6.87 oz

Gross Weight

247 g | 8.71 oz

Scope of Delivery

1x M25-120 fan

Accessories

1x 500 mm PWM extension cable
1x 600 mm D-RGB mainboard connection cable

Screws

4x Fan Screw

Net Weight

195 g | 6.87 oz

Gross Weight

667 g | 23.53 oz

Scope of Delivery

3x M25-120 D-RGB fans

Accessories

2x 500 mm PWM extension cable
1x 600 mm D-RGB mainboard connection cable

Screws

12x Fan Screw
